TH-55VF2W
An ideal solution to create large engaging video walls with an ultra-thin narrow frame and usage in digital signage, broadcast, and control rooms.
PRODUCT DETAILS
Introducing the world's most seamless video wall with a 0.88mm bezel-to-bezel distance, high brightness, and 24/7 operation ready enabling a simplified and seamless multi-screen system for signage, events, and surveillance applications.
KEY FEATURES
- 55" frameless D-LED LCD, 500cd/m², 0.88 mm bezel to bezel, 24/7 operation, IPS panel with anti-glare surface (Haze 28%)
- Advanced uniformity for the best image quality
- DisplayPort UHD daisy chain functionality
- Durable failover and failback function with simplified workflow solution
- Supports reverse scan and frame control to improve multi-screen video visibility
- General Information
- Manufacturer
- Panasonic
- Manufacturer Website Address
- http://www.panasonic.com
- Brand Name
- Panasonic
- Product Series
- VF2
- Product Type
- Digital Signage Display
- Technical Information
- Video Wall Compatible
- Yes
- Bezel Width (Bottom)
- 17.3 mil
- Bezel Width (Top)
- 17.3 mil
- Bezel Width (Left)
- 17.3 mil
- Bezel Width (Right)
- 17.3 mil
- Panel Technology
- In-plane Switching (IPS) Technology
- Operation Hours
- 24 Hours/7 Days
- Display & Graphics
- Number of Screens
- 1
- Viewable Screen Size
- 54.60"
- Display Screen Type
- LCD
- Display Resolution
- 1920 x 1080
- Response Time
- 8 ms
- Aspect Ratio
- 16:9
- Backlight Technology
- Direct LED
- Orientation
- Portrait
- Video
- Scan Format
- 1080p
- Native Contrast Ratio
- 1,100:1
- Brightness
- 500 Nit
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- DVI
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of HDMI Inputs
- 1
- Number of DisplayPorts
- 1
- RS-232C Input
- Yes
- RS-232C Output
- Yes
- Number of Network (RJ-45) Ports
- 1
- Number of Audio Line Out
- 1
- Number of DVI-D Ports
- 2
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Minimum Operating Humidity
- 20%
- Maximum Operating Humidity
- 80%
- Physical Characteristics
- Mount Type
- Wall Mountable
- Hanging Mount
- Installation Type
- Hanging
- Height
- 26.8"
- Width
- 47.7"
- Depth
- 3.8"
- Weight (Approximate)
- 50.71 lb
- Miscellaneous
- Application/Usage
- Control Room
