- General Information
- Manufacturer
- Legrand Group
- Manufacturer Website Address
- http://www.legrand.us
- Brand Name
- Ortronics
- Packaged Quantity
- 5
- Packing
- Pack
- Product Type
- Network Connector
Shielded Category 6A field terminable PCB wired 8 position modular plugs, able to be terminated to either T568A or B wiring, 5 pack of plugs, no special tools required. Supports 22-26AWG solid conductors and 23-26AWG stranded conductors. Installer friendly lacing sled with attached wiring label supports accurate IDC termination with parallel joint pliers. Printed circuitry offers better control and eliminate noise between conductors and 50 micro inch plated plug contacts. Supports up to 5 re-terminations. Condense size of the terminated plug makes this plug compatible with most modular applications. Qualified to 1.5 amps for PoE applications.
- Technical Information
- Connector Type
- RJ-45 Network - Male
- Connector Details
- 1 x RJ-45 Network - Male
- Connector Gender
- Male
- Shielding
- Yes
- Compatible Wire Gauge
- 22-26 AWG
- 23-26 AWG
- Features
- PoE
- PoE+
- 4-Pair Power over Ethernet (4PPoE) Support
- Stranded
- Physical Characteristics
- Height
- 0.5"
- Width
- 0.6"
- Depth
- 2.7"
- Miscellaneous
- Environmentally Friendly
- Yes
- Country of Origin
- China
