- General Information
- Manufacturer
- In Win Development, Inc
- Manufacturer Website Address
- http://www.in-win.com.tw
- Brand Name
- In Win
- Product Series
- BL
- Product Type
- Computer Case
Design Philosophy
A small 11.5L SFF chassis with optimal thermal and acoustic performance.
High Compatibility
It is compatible with standard desktop components, which makes the installation easier and provides a great expandability when needed.
Detachable Drive Bay Cage
For easy installation
Multi-Enjoyment
Designated Infrared Receiver position to support Media Center and optional internal amplifier.
Tool-Free
- Screwless Expansion Slots Clip
- Optional screwless design- ODD/FDD/HDD bays, expansion slots,and side cover clips for easy installation.
- Screwless ODD Bay Clips
- Screwless Top Cover Clips
- Screwless FDD/HDD Bays Clips
Excellent Thermal Solution
?PPCT
Optional the innovative partition plate cooling technology (PPCT) maximizes performance while providing a quiet and cooling environment.
?Cooling Fan
Built-in 80x80x25mm fan for better system cooling.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Motherboard Supported
- Micro ATX
- Mini ITX
- Number of Fans Supported
- 1
- Fan Size Supported
- 3.15"
- Features
- Removable Air Filter
- Intrusion Switch
- Bays
- Number of External 5.25" Bays
- 1
- Number of External 3.5" Bays
- 1
- Number of Internal 3.5" Bays
- 2
- Number of Internal 2.5" Bays
- 1
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 4
- USB Port Details
- 2 x USB 3.0
- 2 x USB 2.0
- 4 x USB 2.0
- Front USB
- Yes
- Total Number of Audio In Ports
- 1
- Front Audio In
- Yes
- Total Number of Audio Out Ports
- 1
- Front Audio Out
- Yes
- Power Description
- Power Supply Installed
- Yes
- Power Supply Wattage
- 300 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Product Material
- Steel
- Cooler Type
- Fan Cooler
- Form Factor
- Desktop
- Maximum CPU Cooler Height
- 2.83"
- Maximum GPU Length
- 7.68"
- Height
- 13"
- Width
- 3.8"
- Depth
- 16.1"
- Weight (Approximate)
- 13 lb
