- General Information
- Manufacturer
- Hanwha Group
- Manufacturer Website Address
- http://www.hanwha.com
- Brand Name
- Hanwha
- Product Type
- Network Camera
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 65.62 ft
- Night Vision Type
- Infrared
- Camera Iris
- Fixed
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2.8"
- Color Supported
- Color
- Field of View
- H: 97° / V: 54° / D: 116°
- Effective Camera Resolution
- 4 Megapixel
- Number of Sensors
- 4
- Video
- Video Formats
- H.264
- H.265
- MJPEG
- H.264H
- H.264M
- H.264B
- H.265B
- H.265H
- H.265M
- Maximum Video Resolution
- 2592 x 1520
- Maximum Frame Rate
- 15 fps
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 3.19 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/1.2
- Exposure
- Shortest Shutter Speed
- 1/12000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Gigabit Ethernet
- Protocols
- IPv4
- IPv6
- TCP/IP
- UDP/IP
- RTP/TCP
- RTCP
- RTSP
- NTP
- HTTP
- HTTPS
- SSL/TLS
- DHCP
- FTP
- SMTP
- ICMP
- IGMP
- SNMPv1/v2c/v3 (MIB2)
- ARP
- DNS
- DDNS
- QoS
- UPnP
- Bonjour
- LLDP
- CDP
- SRTP
- TCP
- UDP Multicast
- MQTT
- ONVIF
- WebSocket
- Digest Authentication
- IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- USB
- Yes
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 23.50 W
- Power Source Type
- PoE+
- Physical Characteristics
- Form Factor
- Dome
- Color Family
- White
- Product Color
- White
- Diameter
- 7.9"
- Weight (Approximate)
- 3.04 lb
- Environmental Conditions
- Minimum Operating Temperature
- -40°F (-40°C)
- Maximum Operating Temperature
- 131°F (55°C)
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- Day/Night
- Built-in IR LED
- HTTPS Encryption
- Ingress Protection
- Motion Detection
- Vehicle Detection
- Human Detection
- Privacy Masking
- White Balance
- Gain Control
- Impact Protection Rating
- IK09
- Ingress Protection Rating
- IP66
