Best choice for scale-out storage in data centers
- The ASUS P9D-MH/SAS/10G-DUAL is a micro ATX form factor serverboard featuring the latest Intel® Xeon® E3-1200 v3 processor family, Broadcom® 10Gb/s Ethernet, dual server-class Intel® Ethernet I210 LAN, LSI SAS 2308 controller, SATA 6Gb/s storage, and ASUS digital power delivery.
- The P9D-MH/SAS/10G-DUAL is tailor-made for Apache™ Hadoop® storage servers to handle big data using large-scale commodity hardware and can also be applied to other high-end storage server applications.
- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://usa.asus.com
- Brand Name
- Asus
- Product Type
- Server Motherboard
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C224
- Total Processor Supported
- 1
- Processor Socket
- Socket H3 LGA-1150
- Processor Supported
- Core i3
- Pentium
- Celeron
- Xeon
- 64-bit Processing
- Yes
- Memory
- Number of Memory Slots
- 32
- Memory Form Factor
- UDIMM
- Maximum Memory Supported
- 32 GB
- Memory Standard
- DDR3-1600/PC3-12800
- DDR3-1333/PC3-10600
- Memory Technology
- DDR3 SDRAM
- Memory Speed Supported
- 1600 MHz
- 1333 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- Serial ATA/300
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 1+0
- Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Manufacturer
- ASPEED
- Graphics Controller Model
- AST2300
- Graphics Controller Memory
- 32 MB
- Graphics Memory Technology
- DDR3 SDRAM
- Graphics Memory Accessibility
- Shared
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 3.0
- PCI Express Standard
- PCI Express 3.0
- PCI Express 2.0
- Total Number of PCI Express Slots
- 3
- Number of PCI Express x1 Slots
- 1
- Number of PCI Express x8 Slots
- 2
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 2
- Number of USB 3.0 Ports
- 2
- VGA
- Yes
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- PS/2 Port
- Yes
- Number of PS/2 Ports
- 1
- Onboard Interfaces
- Number of SATA Interfaces
- 6
- Total Number of Onboard USB Ports
- 5
- Number of Onboard USB 2.0 Ports
- 2
- Number of Onboard USB 3.0 Ports
- 2
- Onboard LEDs Header
- Yes
- Onboard Audio Header
- Yes
- Power Description
- Power Supply Supported
- ATX12V
- Physical Characteristics
- Form Factor
- Micro ATX
- Width
- 9.6"
- Depth
- 9.6"
